Answer: Yes, we provide a true end-to-end service. We offer a full-chain service—from product design optimization to finished product delivery:

Free DFM Analysis: Before mold opening, our engineering team will conduct a comprehensive Design for Manufacturability (DFM) analysis of your 3D model, simulate metal flow (mold flow analysis), predict and address potential porosity, shrinkage, and deformation issues, and optimize the gate design to reduce defect rates.

Precision Mold Manufacturing: We have our own high-standard mold workshop, using premium steel grades such as H13 and SKD61. Equipped with wire EDM machines and high-speed CNC machines, we ensure mold precision reaches ±0.005mm.

Integrated Production: We offer a complete production line—from high-pressure die casting/low-pressure die casting to CNC precision machining and surface treatment (spraying, electroplating, anodizing). Simply provide us with a design concept, and we’ll deliver fully finished components ready for direct assembly. Quick response: From drawing confirmation to the delivery of the T1 sample, the fastest turnaround time is only 15–20 days.

Answer: Quality control is the lifeblood of die casting. We employ automotive-grade process controls to eliminate defects:

Vacuum Die Casting Technology: For parts with high performance requirements, we employ a vacuum-assisted die-casting process that evacuates air from the mold cavity, significantly reducing porosity and increasing part density by more than 30%. These parts can even undergo T6 heat treatment without developing bubbles.

Real-time Process Monitoring: Each die-casting machine is equipped with a real-time monitoring system that collects and locks critical parameters—such as injection speed, pressure, and temperature—at millisecond-level resolution, ensuring process consistency for every molding cycle.

Full-size Inspection Capability: The laboratory is equipped with a three-coordinate measuring machine (CMM), an X-ray flaw detector, and a spectrometer. For each batch, a full-size inspection report (FAI) must be prepared for the first part produced. Critical dimensions undergo CPK statistical analysis to ensure dimensional stability in mass production (CPK > 1.33).

Nondestructive Testing (NDT): We can perform 100% X-ray inspection or air-tightness testing on critical load-bearing components according to customer requirements, ensuring zero internal defects.

Answer: We are committed to reducing your long-term amortization costs through high-quality molds.

Transparent mold quotation: Mold costs are precisely calculated based on dimensions, complexity, steel grade (such as H13, SKD61, 8407), and cavity count (e.g., 1-cavity, 2-cavity, etc.), with no hidden fees.

Ultra-long mold life commitment:

• Aluminum alloy mold: Guaranteed service life ≥ 100,000 cycles.
• Zinc alloy mold: Guaranteed service life ≥ 500,000 cycles.

If the mold prematurely fails due to steel or heat treatment issues, we promise free repair or re-opening.

Mold Ownership and Custody: The mold remains the property of the customer. We provide lifetime free maintenance services (including regular polishing and replacement of wear parts). You are welcome to conduct a video inspection of the mold at any time, or have it inspected by a third party.

Flexible design changes: During product iterations, we offer modification services. Minor adjustments can be completed within 3–5 days; for major changes, we only charge for materials and labor costs, and the T1 sample will be re-validated.

Answer: We are highly proficient in the properties and applications of various alloy materials and can recommend the optimal solution based on your operating conditions.

Aluminum alloy series:

• ADC12/A380: Highly versatile and with excellent fluidity, suitable for thin-walled, complex parts (such as communication housings and power tool casings).
• A356/A360: Excellent toughness and ductility, suitable for T6 heat treatment, high strength, and ideal for load-bearing structural components (such as automotive parts and brackets).
• Silafont-36/ AlSi10MnMg: A high-strength alloy meeting European standards, offering both high strength and high elongation.

Zinc Alloy Series:

• Zamak 3/5: Excellent plating performance, high strength, suitable for precision small parts, hardware decorative components, and lock accessories. Customized special features:
• High thermal conductivity: High-purity aluminum specifically designed for radiators.
• Corrosion-resistant: Special alloy formulation + specialized passivation treatment, passing a salt spray test for over 500 hours.
• Material Certification: Each furnace batch of metal material is accompanied by a spectral analysis report, ensuring that the chemical composition conforms 100% to the standards (ASTM, DIN, GB, JIS).

Answer: Our core strength lies in offering a one-stop turnkey solution, helping you significantly shorten your supply chain.

Precision CNC Machining: With our own machining center, we can perform high-precision milling, drilling, tapping, and boring on die-cast blanks, achieving an accuracy of up to ±0.01 mm and ensuring perfect assembly.

Surface Coating: Automatic spray coating line, supporting powder coating, liquid paint, and fluorocarbon coating. Customizable colors (Pantone/RAL), with adhesion testing performed.

Electroplating and Anodizing:

Zinc alloy: nickel-plated, chrome-plated, gold-plated, antique bronze-finished, etc., passing the CASS test.

Aluminum alloys: Hard anodizing, conductive oxidation, micro-arc oxidation—wear-resistant and corrosion-resistant.

Other processes: wire drawing, sandblasting, polishing, laser marking, screen printing, hot-dip galvanizing, Dacromet treatment, and more.

Component Assembly: We offer services including press-fit nuts, bearing press-in, threaded insert installation, and even complete unit assembly and testing.

Answer: We have a large-scale production base specifically designed for delivering large volumes:

• Powerful equipment cluster: We have 20 cold/hot chamber die casting machines (ranging in clamping force from 88T to 2800T, covering the entire spectrum), with a monthly production capacity of up to 1 million parts.
• Automated production line: Key processes—including robotic automatic part retrieval, automatic application of mold-release agents, and automatic edge trimming—are fully automated. The line operates 24 hours a day without interruption, boosting efficiency by 50% and minimizing human error to the lowest possible level.
• Flexible Production Scheduling and Inventory Management: For long-term cooperative customers, we implement a VMI (Vendor-Managed Inventory) model. Based on your forecasts, we proactively manufacture semi-finished or finished products in advance to achieve JIT (Just-In-Time) delivery. Urgent orders can be shipped within 7 days.
• Parallel Management of Multiple Projects: A mature project management (PM) system ensures that orders from multiple clients proceed in parallel without interfering with each other, guaranteeing on-time delivery.

Answer: By leveraging technological cost reductions and economies of scale, we offer you the most competitive total cost of ownership (TCO):

Lightweight design: Through topology optimization and CAE simulation, while maintaining structural integrity, we reduce wall thickness and eliminate redundant material, directly lowering both the weight per part and material costs (typically achieving weight reductions of 10% to 20%).

Near-net-shape manufacturing: High-precision molds minimize the need for subsequent CNC machining, saving on costly machining time and tooling expenses. With loss.

Waste Recycling Mechanism: Runner material and scrap parts generated from die casting are immediately remelted and reused within the factory, achieving a material utilization rate of over 95%. The resulting cost savings are passed on to our customers.

Tiered Pricing and Rebates: We offer highly attractive tiered pricing based on annual purchase volume. Larger volumes may also qualify for year-end rebates or discounts. Mold fee refund policy.

Logistics Optimization: Professional packaging design solutions to maximize container load rates and reduce shared ocean freight costs.

Answer: Compliance is our passport to entering the global supply chain.

• System Certification: The factory is certified under the ISO 9001 quality management system; automotive industry customers can obtain IATF 16949 certification (if applicable).
• Environmental Compliance: All products comply with EU RoHS, REACH, and the U.S. California Proposition 65 regulations. The surface treatment workshop holds a comprehensive environmental discharge permit.
• Material Traceability: The primary raw materials—aluminum ingots and zinc ingots—are sourced from well-known brands. Each batch is accompanied by the manufacturer’s material certification, ensuring that no conflict minerals are used and that the materials meet ESG requirements.
• Social Responsibility: Ensure labor rights and reduce the supply chain ethical risks for brand owners through SA8000 or similar social responsibility audits.

Answer: We welcome partners at every stage of development. Our process is transparent and highly efficient:

Flexible MOQ:

• Trial Orders / Prototyping: You can get started with as few as 50-100 pieces (using soft tooling or existing cavities) to help you quickly validate the market.
• Mass Production: Depending on the size of the model, the standard MOQ ranges from 500 to 1,000 pieces.
• Standard Process: RFQ/DFM → Quotation → Contract & Tooling Deposit → Mold Manufacturing (15-30 days) → T1 Sample Approval → Pilot Run → Mass Production → Delivery.

Payment Terms:

• Tooling Cost: 50% advance payment, with the balance paid upon approval of T1 samples.
• Bulk Orders: 30% T/T deposit, with the balance paid against the copy of the Bill of Lading (B/L); L/C at sight is also accepted.
• IP Protection: We sign strict Non-Disclosure Agreements (NDAs). All molds and customer data are stored in independent, encrypted systems and will never be disclosed to third parties.

Answer: We fully understand the unique nature of custom/non-standard products. Once a quality issue arises, we immediately activate our rapid response mechanism:

• Minor Issues: We prioritize providing remote technical guidance via video conference to assist your team with on-site repair or adjustments.
• Major Defects: If the items are confirmed to be unrepairable locally, we will immediately arrange a Rush Replacement free of charge and cover the associated logistics costs to ensure your final delivery is not affected.
• On-site Support: For extremely complex issues that must be resolved in person, we can dispatch engineers to your location (subject to specific contract terms).

We strictly adhere to international standards for complaint handling:

• 8D Report: Within a specified timeframe after receiving a complaint (e.g., a preliminary plan within 24 hours, and a full report within 5 working days), we will provide a comprehensive 8D Report (Eight Disciplines Problem Solving).
• Root Cause Analysis: The report will include a Root Cause Analysis, interim containment actions, and long-term preventive/corrective measures to ensure the same issue is eliminated at the source.

“We are technically proficient, compliant, resilient, and ready to be your long-term strategic partner.”
